CNC Lathe Trainer Stepper
Specification:-
|
Bed Type |
Flat / 45 Degrees Slant |
|
Keyboard Type |
Emulated / Standard |
|
Chuck Size |
100 mm (Dia) |
|
Chuck Type |
Hydraulic / Manual |
|
Maximum Turning Diameter |
40 mm |
|
Maximum Turning Length |
250 mm |
|
Center Height |
100 mm |
|
Swing over Cross Slide |
60 mm |
|
Swing Over Bed |
200 mm |
|
Distance between Centre |
320 mm |
|
Controller |
Cut Viewer |
|
Control System |
PLC Based Control System |
|
Operating Software |
Cut Viewer |
|
Positioning |
0.010 mm |
|
Repeatability |
+- 0.015 mm |
|
Resolution |
0.010 mm |
|
Spindle Motor |
AC Servo |
|
Spindle Motor Capacity |
2 HP |
|
Spindle RPM |
100 to 4000 RPM with VFD |
|
Spindle Nose Taper |
A 2-3 / MT 3 |
|
C Axis (Optional) |
C Axis with Brake |
|
Axis Motor and Drive |
Stepper Motor with Stepper Drives |
|
X-Axis Travel |
100 mm |
|
Z-Axis Travel |
300 mm |
|
Ball Screw X / Z |
Ø25 x 5 - C3 Class |
|
Feed Rate |
0 to 1,200 mm/min |
|
Rapid Travel |
1,200 mm/min |
|
Turret Type |
Automatic |
|
Number of Stations |
4 / 8 |
|
Tool Cross Section |
12 mm x 12 mm |
|
Tailstock Base Stroke |
170 mm |
|
Tailstock Actuation |
Hydraulic/ Manual |
|
Lubrication |
Automatic |
|
Coolant |
Automatic |
|
FMS Compatibility |
Provided |
|
Dimension in mm |
1480 x 800 x 1200 mm |
|
Power Supply |
230V, Single Phase |
